Real-World Compression Testing for Electronics

The SUNRISE SR-225 simulates pocket/purse compression forces with high-elasticity rubber & denim to validate structural integrity of phones, PCBs, and displays. Dual-station design accelerates QA testing.

H2: Key Features

✔ Dual-Station Efficiency: Test 2 devices simultaneously (Mitsubishi PLC control)
✔ Precision Compression: 10-120Kgf adjustable pressure (SMC pneumatics)
✔ Real-World Simulation: Elastic rubber + denim contact surfaces
✔ Certification Ready: Complies with IEC 62368-1 squeeze tests

H3: Technical Specifications

H2: Compliance & Applications

Standards:

• IEC 62368-1 Ed.3 (2023)
• OEM-specific compression protocols

Use Cases:

• Smartphone LCD/OLED panel durability
• PCB flex resistance validation
• Wearable device enclosure testing

H3: Testing Workflow

1. Mount samples in dual test stations
2. Set parameters:
   • Pressure: 50Kgf (default for phones)
   • Speed: 20 compressions/minute
3. Initiate test: Auto-stop at preset cycles
4. Evaluate: Post-test functional/visual inspection

Visual Assets

Image File: sunrise-sr225-dual-station-compression.jpg
ALT Text: “SR-225 soft pressure tester evaluating two smartphones simultaneously”

H2: Package Contents

• Main unit with dual test stations
• High-elasticity rubber & denim pads
• Mitsubishi touchscreen controller
• Calibration certificate (NIST-traceable)

H3: SUNRISE Advantages

• OEM-Approved: Pre-loaded Samsung/Apple test profiles
• Data Precision: Optional pressure sensor (0.1Kgf resolution)
• Space-Saving: 530×470mm footprint fits lab benches

After-Sales Support

• 18-month pneumatic system warranty
• Free compression test protocol guide
• On-site training available
