Precision Friction Coefficient Tester for Material Science
The SR-204B Coefficient of Friction Tester from SUNRISE delivers laboratory-grade measurement of static and dynamic friction coefficients, compliant with ISO 8295, ASTM D1894, and GB 10006 standards. This PLC-controlled system features 0.001N resolution for accurate characterization of films, packaging materials, and industrial textiles.
H2: Key Features of Our Friction Coefficient Tester
✔ Dual Measurement: Simultaneously records static & dynamic coefficients
✔ High Precision: 0.001N resolution force sensor (China’s highest accuracy)
✔ Automated Operation: PLC control with LCD touch interface
✔ Standard Compliance: Validates to ISO 8295 and ASTM D1894
H3: Technical Specifications
| Parameter | Specification |
|---|---|
| Force Range | 0-2N (±0.001N) |
| Test Speed | 0-100mm/min |
| Slider Weight | 200±2g (customizable) |
| Sample Size | 63×63mm (top), 80×200mm (base) |
H2: Industry Applications
Packaging:
- Plastic film slip performance (critical for VFFS machines)
- Label stock adhesive compatibility
Textiles:
- Nonwoven fabric handling characteristics
- Sportswear fabric glide performance
Industrial Materials:
- Conveyor belt friction optimization
- Rubber gasket sealing performance
H3: Testing Methodology
- Prepare samples per ASTM D1894 requirements
- Mount specimens on degaussed test platform
- Select test parameters:
- 50mm/min standard speed
- 200g slider weight (default)
- Initiate automated test sequence
- Review printed report showing:
- Static coefficient (μs)
- Dynamic coefficient (μk)
- Force-time graph
Image Optimization
- File Name: sunrise-sr204b-friction-tester-operation.jpg
- ALT Text: “SR-204B friction coefficient tester measuring plastic film slip properties”
H2: Complete Package Includes
- Main testing unit with touchscreen
- Micro printer for automatic reports
- Standard 200g slider
- Download ASTM D1894 test protocol
H3: Why Choose This Friction Tester?
- Regulatory Ready: Pre-loaded test modes for major standards
- Data Rich: Stores 100+ test results with statistical analysis
- Research Grade: 0.001N resolution supports R&D applications
After-Sales Support
• 18-month sensor warranty
• Calibration service with NIST traceability
• On-site training available
Order Your Friction Tester
📞 +86 15992719785
📧 [email protected]
