Key Features
✔ Dual-Chamber Control: Independent temperature/time settings for parallel testing
✔ Precision Heating: PID-controlled MCU (±2°C), SIEMENS™ solid-state relays
✔ Multi-Standard Compliance: ISO 105-C01 to C06, AATCC 61, GB/T 3921
✔ Safety Systems: Overheat protection + water level detection
Technical Specifications
| Parameter | Specification |
|---|---|
| Chamber Capacity | 2–24 cups (550mL/1200mL options) |
| Temperature Range | 0–100°C (±2°C) |
| Rotation Speed | 40±2 rpm |
| Timer Range | 0.1–9999 minutes |
| Power Supply | 220V, 50Hz |
| Weight | 75kg |
Compliance & Applications
Standards:
- ISO: 105-C01 to C06, 105-D06
- AATCC: 61, 132, 28
- GB/T: 3921, 5711
- M&S: C4, P3B
Use Cases:
- Textile dye wash fastness testing
- Dry-cleaning performance validation
- Quality control for apparel manufacturers
Package Contents
- Main unit with stainless steel chambers
- Wash cups (configurable quantities)
- Operation manual
- Calibration certificate
Optional Models:
- SR-307W: White panel (integrated controls)
- SR-307L: Blue panel (separate controls)
Why Choose SR-307?
- High Throughput: Test up to 24 samples simultaneously
- Lab-Grade Accuracy: PID temperature control
- Durability: Stainless steel construction
Support & Ordering
📞 Contact Sales: Jess (+86 15992719785, WeChat/WhatsApp)
✉ Email: [email protected]
🌐 Website: www.sunrisedg.com
