Summary:
The Intelligent Temperature Detect Gate uses a high-precision infrared temperature sensor with a sensingdistance of 0.5-1 meters. It has high precision and high resolution and is immune to the environment andsunlight. The measurement error at room temperature is ± 0.5 ° C, and the resolution is 0.02 ° C. Theinitial temperature setting is 37.3 ° C (adjustable). The actual body temperature of the human body isdisplayed when the detection door is in operation. An alarm is issued when the temperature exceeds 37.3 ° C.
Non-contact initial screening for abnormal body temperature, fast detection speed, can prevent personnel contact with cross-infection.It has a 7-inch LCD screen, which can display the information of measuring temperature, alarm temperature, alarm times, number of people passing through, compensation parameters and so on.
Main Parameters:
| Items | Quick Detect Infrared Human Body Temperature Security Door,
Intelligent Temperature Detect Gate |
| Response time/ Probe time | 0.1S/0.5S-1.5S |
| Measure Range | 30℃~42℃ |
| Temperature Measure Accuracy | ±0.5℃ |
| Repeated accuracy | ±0.2℃ |
| Temperature sensor module | MELEXIS |
| Measure Position and Distance | Forehead, Wrist / 5~15cm |
| Display Screen | 7 inch colour touch screen |
| Frame Dimension | 2202*820*550mm (H*W*D) |
| Channel Dimension | 2000*700*550mm (H*W*D) |
| Power | 110~240V |
Details
| Model | SR-8811 |
|---|---|
| MOQ | 1 Set |
| Brand | SUNRISE |
| Lead Time | 5~15 days after payment |
| Country of Origin | China |
| Package | Standard export wooden case. |
| OEM & ODM | Support |
